Tube Laser Cutting Machine
ATC 6020L SERIES FIBER LASER
Enclosed Φ 200 Tube laser
Three chuck, Precise & Zero tail
Advanced three-chuck tube laser cutting solution designed for full-length pipe processing, zero tail cutting capability, and high precision industrial applications.

Product Showcase

Watch our product in action, and product images for better understanding

    Key Features

  • Full stroke three chuck cutting system
  • Zero tailing material optimization
  • High speed gear driven chuck rotation
  • Dual jaw and roller support design
  • Advanced tube nesting software integration
  • High precision and stable cutting performance
  • Intelligent bus control system

    Key Applications

  • Structural tube fabrication
  • Heavy engineering and infrastructure
  • Automotive and chassis manufacturing
  • Furniture and pipe processing industries
  • Industrial fabrication and OEM production

Material Thickness & Laser Power Chart

Compare cutting capacities from 3kW to 30kW to select the ideal laser power for your material thickness requirements.

View Full Chart ->
×

Material Thickness & Laser Power Chart

Laser Power 3 kW 4 kW 6 kW 8 kW 10 kW 12 kW 15 kW 20 kW 30 kW
Cutting Thickness on Metals mm (inch)
Mild Steel (MS) (O₂) 20 (3/4") 22 (7/8") 25 (1")* 28 (9/8")* 30 (19/16")* 40 (25/16")* 45 (7/4")* 50 (31/16")* 60 (19/8")*
Mild Steel (MS) (N₂ / Air) 6 (1/4") 6 (1/4") 8 (5/16") 10 (3/8") 12 (1/2") 12 (1/2") 16 (5/8") 20 (13/16") 25 (1")*
Stainless Steel (SS) (O₂) 10 (3/8") 10 (3/8") 10 (3/8") 10 (3/8") 10 (3/8")* 10 (3/8") 10 (3/8") 10 (3/8") 10 (3/8")
Stainless Steel (SS) (N₂ / Air) 8 (5/16") 10 (3/8") 16 (5/8")* 20 (13/16") 25 (1")* 30 (19/16")* 32 (5/4")* 35 (11/8")* 40 (25/16")*
Aluminum (AL) (N₂) 8 (5/16") 10 (3/8") 16 (5/8")* 20 (13/16") 25 (1")* 30 (19/16")* 32 (5/4")* 35 (11/8")* 40 (25/16")*
Brass (Br) (N₂) 6 (1/4") 8 (5/16") 12 (1/2") 16 (5/8") 20 (13/16") 25 (1")* 30 (19/16")* 32 (5/4")* 35 (11/8")*
Copper (Cu) (O₂) 5 (3/16") 6 (1/4") 8 (5/16") 10 (3/8") 12 (1/2") 16 (5/8") 18 (11/16") 20 (13/16") 22 (7/8")
Galvanized Iron (GI) (N₂ / Air) 3 (1/8") 3 (1/8") 3 (1/8") 3 (1/8") 3 (1/8") 3 (1/8") 3 (1/8") 3 (1/8") 3 (1/8")

Overview

The ATC 6020L Series is designed for high-efficiency and high-precision tube cutting, especially for long pipes and complex profiles.

With a three-chuck configuration, the machine ensures full-length cutting with minimal or near-zero tailing, maximizing material utilization and reducing waste.

Its advanced machine structure, intelligent control system, and high-speed performance make it ideal for manufacturers seeking higher productivity, superior precision, and cost-efficient tube processing.

Technical Specifications

Specification Option 1
Model ATC 6020L
Laser Power 3KW – 6KW
Acceleration Up to 1G
Positioning Accuracy ±0.03 mm / 1000 mm
Repositioning Accuracy ±0.02 mm / 1000 mm
Round Tube Capacity Φ20 – Φ220 mm
Square Tube Capacity Up to 155 × 155 mm
Maximum Tube Length Up to 7100 mm
Chuck Type Three Pneumatic Chucks
Tail Length (Scrap) Near Zero Tailing
Control System FSCUT5000A Tube Cutting System
Maximum Axis Movement Speed Up to 100 m/min
Chuck Rotation Speed Up to 100 r/min

Technology Highlights

⚠️ No Data Found

Product Description

Three-Chuck Full Stroke Cutting System

The machine is equipped with a full stroke three-chuck system that enables continuous clamping and cutting throughout the entire tube length. This ensures higher material utilization and significantly reduces scrap generation.

Advanced Pneumatic Chuck Stability

The fully enclosed pneumatic chucks provide strong clamping force with effective dust protection. The dual-row jaw design enhances cutting stability and accuracy. The front chuck includes dual functionality with roller support for long pipes and groove clamping for short components.

High-Speed Cutting Performance

The gear-driven chuck system allows faster rotation and improved cutting efficiency. With optimized motion performance, the machine delivers stable and high-speed tube processing for industrial production.

Intelligent Tube Cutting Control System

Equipped with the FSCUT5000A tube cutting bus control system, the machine ensures fast response, smooth motion, and precise cutting. The integrated TubesT nesting software optimizes material usage, enables common edge cutting, and supports automatic counting functions.

Zero Tail Cutting Advantage

The three-chuck design allows near-zero tail cutting capability. The third chuck can independently clamp and retract short pipes, ensuring minimal wastage and maximum efficiency.

High-Speed Motion & Servo System

With acceleration up to 1G and maximum axis movement speed up to 100 m/min, the system ensures fast and efficient production. The machine is powered by a high-performance servo system (Yaskawa), ensuring precision and stability during operation.

Frequently Asked Questions

Everything you need to know about the ATC 6020L SERIES FIBER LASER

1. What is the ATC 6020L tube laser cutting machine used for?

The ATC 6020L is a high precision tube laser cutting machine designed for structural tubes, automotive components, furniture manufacturing, and industrial fabrication. It is ideal for applications requiring full length pipe processing with minimal material wastage.

2. What is the maximum tube length the ATC 6020L can process?

The ATC 6020L can process tubes up to 7.1 meters (7100 mm) in length, making it suitable for long pipe applications and large structural components.

3. What makes the three chuck system important in tube laser cutting?

The three pneumatic chuck system enables full stroke cutting across the entire tube length. It ensures continuous clamping, better stability, and allows processing of both long and short tubes with high precision.

4. Does the ATC 6020L support zero tail cutting?

Yes, the machine offers near zero tailing, meaning almost the entire tube is utilized. The third chuck holds and processes the remaining section, significantly reducing scrap and improving material efficiency.

5. What laser power options are available in ATC 6020L?

The ATC 6020L supports 3 kW to 6 kW fiber laser power, making it suitable for a wide range of tube cutting applications with high speed and precision.

6. What tube sizes can the ATC 6020L handle?

The machine supports:

  • Round tubes from Φ20 mm to Φ220 mm
  • Square tubes up to 155 × 155 mm

This makes it versatile for different industrial tube profiles.

7. How does the ATC 6020L improve material utilization?

With zero tail cutting capability, advanced tube nesting software, and full stroke processing, the machine maximizes raw material usage and reduces overall production cost.

8. What control system is used in the ATC 6020L?

The machine is equipped with the FSCUT5000A tube cutting system, which ensures fast response, smooth motion control, accurate cutting, and intelligent production management.

9. Is the ATC 6020L suitable for high speed industrial production?

Yes, with up to 1G acceleration, 100 m/min axis speed, and gear driven chuck rotation, the machine delivers high speed and consistent output, making it ideal for mass production environments.

10. Why choose a three chuck tube laser machine over a standard two chuck machine?

A three chuck system offers full length cutting, near zero scrap, better stability for long pipes, and higher precision, making it the preferred choice for manufacturers focused on efficiency, cost savings, and high productivity.
